Low Viscosity Flame Retardant Epoxy for Void-Free Transformer Coil Impregnation

Low Viscosity Flame Retardant Epoxy for Void-Free Transformer Coil Impregnation

Place of Origin:

China

Brand Name:

wenyou

Certification:

ISO9001, ISO14001, SGS, and UL

Model Number:

9204

Contact Us
Request A Quote
Product Details
Classification:
Double Components Adhesives
Usage:
Bushings, Switchgears,dry-type Transformers, And Other Insulation Products.
Application:
Indoor Electrical Insulators For Medium And High Voltage Applications
Viscosity At 25°C:
5000 - 7000mPa.s
Density At 25°C:
1.13 - 1.18g/cm3
Vapor Pressure At 25°C:
≤ 0.01Pa
Flash Point:
Around 130°C
Epoxy Value:
5.0 - 5.4Eq/kg
Description:
Excellent Mechanical And Electrical Properties Epoxy Resin For Insulators / Bushings
Payment & Shipping Terms
Minimum Order Quantity
20kg/pail as sample
Price
Negotiable
Packaging Details
20kg/pail, 220kg/barrel, 1200kg/tank
Delivery Time
7 -10 work days
Payment Terms
Normally L/C,T/T
Supply Ability
Plenty of raw material in stock
Product Description

LE-9204/LH-9204: UL 94 V-0 Low-Viscosity Epoxy for Transformer Coil Impregnation & Bushings

Product Overview

LE-9204/LH-9204 is a low-viscosity, flame-retardant epoxy system engineered for void-free impregnation of transformer coils and high-voltage bushings. Featuring UL 94 V-0 certification and exceptional flow characteristics, it penetrates complex winding structures to eliminate air pockets, prevent partial discharge, and enhance dielectric strength. Ideal for VPI processes, APG molding, or vacuum casting of dry-type transformers, switchgear, and indoor insulation components up to 40.5 kV.


Key Features & Benefits

Property Advantage
Ultra-Low Viscosity Deep penetration into coil windings for void-free insulation
Flame Safety UL 94 V-0 certified – critical for dry-type transformers & indoor switchgear
Thermal Resilience Withstands >1,000 thermal shock cycles (-40°C to +150°C)
Electrical Integrity High CTI (>600 V) and dielectric strength (>18 kV/mm)
Process Flexibility Compatible with VPI, APG, and vacuum gravity casting
Custom Formulation Adjust LF-630 flexibilizer (0-20 pbw) for stress reduction

Applications

  • Dry-type transformers: Coil impregnation and encapsulation

  • Medium-voltage switchgear (up to 40.5 kV)

  • Bushings and insulators for indoor applications

  • Sensor coils and reactor windings

  • PCB insulation barriers


Technical Formulation

Component Part Ratio (pbw) Function
Epoxy Resin LE-9204 100 BPA-based liquid resin
Anhydride Hardener LH-9204 85 Carboxylic acid curing
Flexibilizer LF-630 0–20 (opt.) Reduces brittleness
Accelerator LZ-622 0.2–1.5 Controls cure speed
Silica Filler Powder 320–390 Enhances mechanicals
Color Paste LC Series 3 (opt.) Visual identification

Cured Properties:

  • Viscosity (mixed): <500 mPa·s (enables deep impregnation)

  • UL 94 Rating: V-0

  • Comparative Tracking Index: >600 V

  • Dielectric Strength: >18 kV/mm

  • Thermal Shock Resistance: Passes IEC 60137 cycling tests


Processing Methods

  1. Vacuum Pressure Impregnation (VPI):

    • Optimal for transformer coils – ensures void-free penetration

  2. Automatic Pressure Gelation (APG):

    • High-volume production of bushings/insulators

  3. Vacuum Gravity Casting:

    • Bubble-free encapsulation for complex geometries


Why Choose This System?

  • Void Elimination: Ultra-low viscosity removes air pockets in windings

  • Fire Safety: Critical UL 94 V-0 rating for indoor electrical equipment

  • Flexibility Control: Tune toughness with LF-630 flexibilizer

  • Accelerated Curing: LZ-622 enables rapid production cycles

  • Industrial Compliance: Meets IEEE C57.12.01 for dry-type transformers


Package Image


Low Viscosity Flame Retardant Epoxy for Void-Free Transformer Coil Impregnation 0

Shipment image


Low Viscosity Flame Retardant Epoxy for Void-Free Transformer Coil Impregnation 1


Example application image



Low Viscosity Flame Retardant Epoxy for Void-Free Transformer Coil Impregnation 2
