casting process Liquid Epoxy Resin and Hardener for Electric Insulators
Liquid Epoxy resin use in APG machine in Electric Insulation
Bi-component alicyclic saturated structure epoxy resin system /liquid can be used to the processes of APG& Conventional casting process under vacuum.
process under vacuum,Excellent UV resistance &heat shock resistance Excellent environmental performance and mechanical properties.
| Epoxy resin | LE-9513 | 100pbw |
| Hardener | LH-9513 | 100pbw |
| Filling | Silica flour(SIO2) | 350-450pbw |
| Color Paste | LC-series* | 3pbw |
|
Epoxy resin
|
LE-9513
|
100pbw
|
|
|
Hardener
|
LH-9513
|
100pbw
|
|
|
Filling
|
Silica flour (SIO2)
|
320-380pbw
|
|
|
Color paste
|
LC-series
|
3pbw
|
|
|
Properties
|
Standard
|
Unit
|
Value
|
|
Viscosity at 25℃
|
ISO 12058
|
mpa.s
|
2000-5000
|
|
Density at 25℃
|
ISO 1675
|
g/cm3
|
1.16-1.20
|
|
Flash point
|
ISO 1523
|
℃
|
About 135
|
Shanghai Wenyou industry co., Ltd. Is located in Fengxian District,Shanghai ,China.It is a professional company engaged in the manufacturing,R&D,sales of the epoxy resin,curing agent and other Products.Our products include epoxy resin,Flame retardant resin,curing agent,outdoor modifier,toughening agent ,epoxy paste,demoulding agent and filler,they are not only sold in china,but also exported to Europe,Southeast Asia,Middle East region and Russia and the other CIS countries.
Q: What is Wenyou epoxy resin used for?
A: Wenyou epoxy resin is used for electric insulation and protection in various applications, including insulators, transformers, PCBs, motors, and electric enclosures. It provides electric insulation, adhesion, and encapsulation for electronic components.
Q: What are the benefits of using Wenyou epoxy resin?
A: The benefits of using Wenyou epoxy resin include:
• Excellent electric insulation properties
• High dielectric strength
• Thermal stability
• Chemical resistance
• Strong adhesion and encapsulation
• Protection against moisture, dust, and mechanical stress
Q: How is Wenyou epoxy resin different from regular epoxy resin?
A: Wenyou epoxy resin is specifically formulated for electric applications and has enhanced electric l insulation properties. It undergoes rigorous testing to meet specific electric standards and requirements.
Q: How is Wenyou epoxy resin cured?
A: Wenyou epoxy resin is cured by mixing it with a suitable hardener or curing agent. The curing process typically involves applying heat or allowing it to cure at room temperature, depending on the specific resin and application requirements.
efficient application.
Q: How should Wenyou epoxy resin be stored?
A: Wenyou epoxy resin should be stored in a cool, dry place, away from direct sunlight and extreme temperatures. It is important to follow the manufacturer's instructions for proper storage and shelf life.
.
