Place of Origin:
CJINA
Brand Name:
WENYOU
Certification:
CE UL ISO
Model Number:
9214
Low factory price,High quality#9214 epoxy resin and hardener for electrical insulators
Liquid Epoxy resin use in APG machine in Electric Insulation
Bi-component alicyclic saturated structure epoxy resin system /liquid can be used to the processes of APG& Conventional casting process under vacuum.
process under vacuum,Excellent UV resistance &heat shock resistance Excellent environmental performance and mechanical properties.
| Epoxy resin | LE-9214 | 100pbw |
| Hardener | LH-9214 | 100pbw |
| Filling | Silica flour(SIO2) | 350-450pbw |
| Color Paste | LC-series* | 3pbw |
| Epoxy resin | LE-9214 |
100pbw
|
|
| Hardener | LH-9214 | 100pbw | |
| Filling | Silica flour (SIO2) | 320-380pbw | |
| Color paste | LC-series | 3pbw |
|
| Properties | Standard | Unit | Value |
| Viscosity at 25℃ | ISO 12058 | mpa.s |
2000-5000
|
| Density at 25℃ | ISO 1675 | g/cm3 | 1.16-1.20 |
| Flash point | ISO 1523 | ℃ |
About 135
|
